Encoder Bridge Configurator
SAS IntelliLink™ Encoder Bridge
Define encoder input, one or two output ports, voltages and diagnostics — then download a PDF or send the configuration to SAS.
Configuration Tool Encoder Bridge
Build your encoder signal converter specification
Select input, output port 1, and optionally output port 2 for a dual bridge (for example BiSS-C in, BiSS-C out, HTL on the second port). The dropdowns use the full 26-protocol catalog — same options in and out. Download a branded PDF or send the spec to SAS.
Encoder
Signal: Not selected
Encoder supply: Not selected
SAS Encoder Bridge
Operation voltage: Not selected
RS485 diagnostic: Not selected
PLC / CNC
Output protocol: Not selected
Output port 2
Second output: Not selected
RS485 & SIL Console — live diagnostic view
The RS485 port is a dedicated supervision link to SAS SIL Console for Encoder Bridges. Encoder telegrams, conversion status, and bridge health are exposed in real time — independently of the production output to your PLC or CNC.
Acceptance & commissioning. During FAT, SAT, and line prove-out, engineers can trace the full signal path: raw protocol frames, CRC results, resolved position, index events, and fault flags — in one session, without tapping the machine interface or adding external analyzers.
- CRC status — frame and telegram integrity
- Protocol binary — raw encoder frame view
- Absolute position — resolved position value
- Error & alarm flags — fault and warning status
- Z counter — index and reference mark events
- Turn / revolution counter — multi-turn count
- Line speed — RS485 link baud rate and comms status
- Bridge operating status — power, mode and readiness
- Encoder link quality — input signal health
- Frame sequence counter — telegram sequence tracking
- Cycle time — update interval and processing latency
All parameters above are available through SIL Console over RS485. No additional diagnostic channel or register configuration is required on the bridge — specify RS485 where acceptance testing needs documented encoder-path verification.
Configuration Summary
Configuration and your notes are copied into the contact form below. You can still edit the message before submitting.
Send your configuration to SAS
Complete the form with your contact details. The message field is pre-filled with your encoder bridge configuration — add machine make/model, controller type or datasheet references if available.
